Overview
The revolutionary fire control system for your preferred LPVO.
Integrated auto-calculated ballistics mount for any caliber.
The X4-FCS™ mount provides real time ballistic calculations using temperature, pressure, humidity, pitch, roll, and heading.
Combining these parameters with user supplied bullet and firearm data, the X4-FCS generates a precision ballistic compensated offset reticle.
Features:
- User-customizable symbology on daylight-readable display
- Designed to meet MIL-STD-810 environmental specs
- Compatible with most 30 mm and 34 mm LPVO scopes
- Manufactured from solid billet aircraft-grade 7075-T6 aluminum
- Designed and manufactured in the USA
X4-FCS is compatible with most 30mm and 34mm Low-Power Variable Optics (LPVOs).
- Athlon - Helos BTR 1-4.5x24 Service Riflescope
- GPO - SPECTRA 6X 1-6x24i both SFP/FFP
- Huskemawoptics - Tactical Hunter 1-6×24 Riflescope
- Kahles - 1-8x
- March Scopes - March Scopes
- Schmidt & Bender - 1-8x24 PM II ShortDot Dual CC
- Swarovskioptik - Z6i 1-6x24, 1-6x24 EE, Z8i 1-8x24
- Vortex - Viper PST GEN 2, Razor HD GEN 2-E
Specifications:
|
Caliber: |
Any |
|
Platform: |
STANAG 4694 (Compatible with STANAG 2324 / Picatinny MIL-STD-1913) |
|
Scope Compatibility: |
Most 30 mm or 34 mm LPVO scopes |
|
Reticle Color: |
Green |
|
External Color: |
Black |
|
Weight: |
22.6 oz (642 grams) with batteries |
|
Dimensions (L,W,H): |
8.2 in x 2.3 in x 3.0 in (209 mm x 59 mm x 77 mm) |
|
Battery Type: |
Supplied - Rechargeable USB-C 18650 (2x) Optional - CR123 (4x) |
|
Battery Life: |
1 year at 10 operating hours per week |
|
Connectivity: |
Bluetooth® Low Energy, Near-Field Communication (NFC), and Ultra-Wideband (UWB). Each can be disabled. |
|
Ballistics Solver: |
Applied Ballistics® |
|
Temperature Rating: |
-40°F to +140°F (-40°C to 60°C) subject to appropriate temperature-rated batteries. |
Includes:
-
Two rechargeable 18650 batteries
-
Two USB-C charging cables
-
Lens cleaning cloth
-
Drawstring bag
-
T15 Torx wrench
-
Loctite® 242
-
Mini flathead screwdriver
-
Bluetooth® USB Dongle
-
Quick Start Guide
-
User Manual
-
Maztech Patch
-
Maztech Stickers
