Pulsar Telos LRF XL50 Thermal Monocular

Main

• Sensor1024x768 @ 12 µm (NETD <40 mK)
• Objective lensF50 / 1.0
• Magnification, x2.5 – 20 (x8 digital zoom)
• Field of view (HxV), degrees / m@100m14x10.5 / 24.6х18.5
• Detection range, m2300

Sensor

• Type uncooled
• Resolution, pixels1024x768
• Pixel pitch, µm12
• NETD, mK<40
• Frame rate, Hz50

Optics

• Objective lensF50 / 1.0
• Magnification, x2.5 – 20 (x8 zoom)
• Field of view (HxV), degrees / m @ 100 m14x10.5 / 24.6х18.5
• Eye relief, mm14

Display

• Type AMOLED
• Resolution, pixels1024x768

Range Performance

• Detection range, m2300

Laser Rangefinder

• Safety class for laser equipment according to IEC 60825-1:20141
• Wavelength, nm905
• Max. measuring range, m1000
• Measurement accuracy, m± 1

Video Recorder

• Video / photo resolution, pixel1024x768
• Video / photo format.mp4 / .jpg
• Built-in memory, GB64

Wi-Fi

• Wireless Protocol Wi-Fi
• Wireless Standard IEEE 802.11 b/g/n/ac (WPA)
• Frequency, GHz2.4 / 5

Environmental Characteristics

• Degree of protection, IP code (IEC60529)IPХ7 (waterproof)
• Operating temperature range, °С-25 – +40

Connections and Compatibilities

• Mount, type1/4"
• Supported Application Stream Vision 2

Power Supply

• Output voltage, V3.0 – 4.2
• Battery type LPS 7i Li-Ion Battery Pack
• Capacity, mAh6400
• Operating time on battery pack (at t=22°C), h *7
• External power supply, V5V, 9V (USB Type-C Power Delivery)

Weight & Size

• Body material rubber armored reinforced plastic
• Dimensions, mm243x72x90
• Weight, kg0.58 (w/o battery) / 0.72 (with the LPS7i battery)
