Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope

Log in for special member pricing. Use "Request Quote" for: RFQs, Bulk discounts, Out-of-stock items, Regulated products, Tax-exempt sales. Please use separate carts to keep free shipping offers. Air freight orders: Submit by 12 PM PST for same-day shipping.

SKU:
Pulsar-PL76585K
UPC:
840284905246
MPN:
PL76585K
Availability:
Shipped from our manufacturers warehouse. You will be notified of any delays. Your card will not be charged until product ships.
Weight:
1.50 LBS
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
  • Pulsar Trail 3 LRF XQ50 3.5 x 14 Thermal Riflescope
Price: $3,199.97

Related Products

Description

Compact and rugged Trail 3 LRF riflescopes built are for professional hunters, forestry specialists and pest control operators. Monoblock design and multi-point Pulsar prism ensure robustness and firm mounting on rail mounts. Top quality thermal imaging combined with precise laser rangefinder and ballistic calculator offers excellent image while ensuring shooting precision. Pulsar Trail 3 LRF XQ50 is built for short- to mid-range shooting in challenging conditions such as fog, humidity, or low-contrast environments. It delivers clear, stable images to help you spot and track targets reliably, even when visibility is limited.

Features:

  • Ergonomic controls
  • Bilateral focusing mechanism
  • Integrated ballistic calculator
  • Recoil activated video recording
  • Full HD extra crisp AMOLED screen
  • New graphic interface
  • Round-shaped PiP mode
  • Built-in laser rangefinder
  • 9 color palettes
  • 3 display shapes
  • 10 reticle shapes
  • 10 zeroing profiles
  • Side incline indication
  • Elevation angle indication
  • Stream Vision 2 support
  • Stream Vision Ballistics support
  • Multipoint Pulsar mounting prism
  • Automatic display deactivation
  • Quick-change rechargeable battery
  • Shadow recording

Specifications:

Main

  • Sensor: @ 17 µm 384x288/17µm
  • Objective lens: F50 / 1.0
  • Magnification, x: 3.5 - 14
  • FOV (HxV), degrees: 7.5
  • FOV (HxV), m@100m: 13.1
  • Diopter Adjustment, D: -5 / +5
  • Detection range: 1800 m

Reticle

  • Click range, H/V, mm at 100m: 1800/1800
  • Click value, H/V, mm at 100m: 9.1
  • Number of preloaded reticles: 10

Sensor

  • Type: Thermal uncooled, microbolometric
  • Resolution, pixels: 384x288/17µm
  • Pixel pitch, µm: 17
  • Sensor NETD, mK: < 25
  • System NETD, mK: < 15
  • Frame rate, Hz: 50

Optics

  • Objective lens: F50 / 1.0
  • Magnification, x: 3.5 - 14
  • FOV (HxV), degrees: 7.5
  • FOV (HxV), m@100m: 13.1
  • Diopter Adjustment, D: -5 / +5
  • Eye relief, mm: 50

Display

  • Type: AMOLED
  • Resolution, pixels: 1920x1080

Laser Rangefinder

  • Max. measuring range, m: 1200
  • Measurement accuracy, m: ± 1
  • Safety class for laser equipmentaccording to IEC 60825-1:2014: 1
  • Wavelength, nm: 905

Video Recorder

  • Video / photo resultion, pixel: 1440x1080
  • Video / photo format: .mp4 / .jpg
  • Build-in memory, GB: 64

Bluetooth

  • Wireless protocol: Wi-Fi
  • Wireless standard: IEEE 802.11 b/g/n/ac (WPA)
  • Frequency, Ghz: 2.4/5

Wi-fi

  • Wireless protocol: Wi-Fi
  • Wireless standard: IEEE 802.11 b/g/n/ac (WPA)
  • Frequency, Ghz: 2.4 / 5

Environmental Characteristics

  • Degree of protection IP code (IEC60529): IP67 (waterproof)
  • Operating temperature range, °С: -25 – +50

Connections and compatibilities

  • Compatible mounts: Multi-point prism
  • Supported application: Stream Vision 2, Stream Vision Ballistics
  • Shock resistance on the smooth-bore rifles, caliber: 12
  • Max. recoil power on rifled weapon (Eo), Joules: 6000

Power supply

  • Output voltage, V: 4.2-3.0
  • Battery type: LPS 7i
  • Capacity, mAh: 6400
  • Operating time on battery pack, h at t=22°С: 12h
  • External power supply, V: 5V/9V USB Type-C

Weight & size

Body material: Magnesium alloy
Dimensions, mm: 271x86x71
Weight, kg: 0.7
SKU: 76585
