EOTech EXPS3-4 Holographic Weapon Sight
Log in for special member pricing. Use "Request Quote" for: RFQs, Bulk discounts, Out-of-stock items, Regulated products, Tax-exempt sales.
Please use separate carts to keep free shipping offers.
Air freight orders: Submit by 12 PM PST for same-day shipping.
- SKU:
- EOTech-EXPS3-4
- UPC:
- 672294600367
- MPN:
- EXPS3-4
- Weight:
- 0.70 LBS
Description
Operator Grade Holographic Weapon Sight
An operator-grade Holographic Weapon Sight built for close-quarter engagements with fast-moving targets.
Reticle Options
EOTECH’s unique reticle patterns are critical to delivering fast target acquisition and MOA accuracy at any range. EOTECH reticles feature a 68 MOA ring surrounding a 1 MOA center dot allowing the shooter to quickly pick up and lock on a target.
EOTECH One Dot Reticle
Our most popular reticle offered, the 68 MOA ring with 1 MOA dot provides three usable aiming points. The aiming points above are based on the following load: .223 cal. 62 gr. 2,900 vel. When using other loads and calibers, the operator will have to establish the ranges associated with the aiming points. When using a shotgun, the 68 MOA ring can be used to represent shot patterns but will vary based on choke and shell selection. For ordering this reticle, the model codes will end in -0.
EOTECH Two Dot Reticle
Our two-dot reticle pattern can be easily distin-guished with or without magnification and offers the benefit of an additional long-range, aiming dot. The aiming points above are based on the following load: .223 cal. 62 gr. 2,900 vel. For ordering this reticle, the model codes will end in -2.
EOTECH Four Dot Reticle
Use this ballistic reticle with 5.56 Nato/.223 Cal with 62 gr M855 FMJ at roughly 2,680 fps with a 14.5" barrel. For ordering this reticle, the model codes will end in -4. Aiming dots on the 4-dot reticle may not be distinguishable without magnification.
Specification
- Finish: Hard Coating
- Fabric/Material: Aluminum
- Magnification: 1 x
- Objective Window Size: 30 mm
- Reticle: 4-Dot
- Illumination Type: Holographic
- Illumination Color: Red
- Brightness Settings: 30
- Eye Relief: Unlimited
- Adjustment Type: MOA
- Adjustment Click Value: 0.5 MOA
- Emitter Type: Enclosed
- Field of View, Linear: 30 yds at 4 in
- Lens Material: Front Window 1/8in Solid Glass & Rear Window 3/16in Laminate, Glass
- Optical Coating: Anti-Reflection coating on external surface, Anti Reflection Coating
- Battery Type: CR123A
- Battery Quantity: 1
- Battery Life: 1000 hours
- Operating Temperature: -40 - 140 Fahrenheit, -4 - 122 Fahrenheit
- Weather Resistance: Water Resistant
- Water Resistance Level: Submersible
- Water Resistant Mark: 10 m, 33 ft
- Shockproof: No
- Fogproof: Yes
- Gun Make: Universal
- Gun Model: Universal
- Length: 3.8 in
- Width: 2.3 in
- Height: 2.9 in
- Weight: 11.2 oz
- Additional Features: Lithium Battery
- Included Accessories: Standard
- Condition: New
- Red Dot Sights-Footprint: Not Applicable
- Magnification Type: Fixed
- Mount Type: Weaver
- Quantity: 1
- Switch Type: Button
- Lens Finish: Fog Resistant, Fog resistant internal optic
- Fit: both 1in Weaver and MIL-STD-1913 rail
- Country of Origin: USA
- Brightness Index: 20 Daylight Settings
- Attachment Type: Picatinny, Weaver
